Mac ULTRA 10 - Modular Fixture Welding Table - 1400 x 1400mm
Mac ULTRA 10 - Modular Fixture Welding Table - 1400 x 1400mm
Mac ULTRA 10 - Modular Fixture Welding Table - 1400 x 1400mm

Mac ULTRA 10 - Modular Fixture Welding Table - 1400 x 1400mm

CODE
MAC-ULTRA10-1400X1400
In stock
Order in for UK Mainland delivery between 14/07/2025 to 23/07/2025
£2,478.80 £2,065.67

Order by 3pm:

Next-day delivery
Made In Britan > Made In Herefordshire > Made In House ULTRA10 is MAC's 2022 Best Selling Heavy Duty Table! Providing Dyson, Ocardo, Ginetta, Bentley Racing, Clayton Engineering plus many more! Our ULTRA10 are the ultimate professional modular welding table fixture system. These tables are designed inhouse using the tab and slot locking interface. Manufactured from high grade S355J2+N All ULTRA tables have a 200mm deep rib sub-frame offering maximum strength and accuracy. The ULTRA10 is supplied with a material thickness of 10mm of the top plates and 10mm sides with chamfer holes. Unlike other imports and cheaper constructions, we design superior sub-frame cross bracing as this is the most critical part of the fixture table to ensure a truly flat and accurate fabrication surface. We design, test and manufacture everything in house and the UK to maintain a high quality of control. As standard all of our tables and tool includes the industry standard 16mm hole pattern (50mm hole centres) to work with all industry fixture 16D tooling. We also offer 28mm fixture points at 100mm centres.
  • ULTRA10 High Grade S355J2+N 10mm Thick Top 10mm Side skirts.
  • 200mm fixture skirt/sides with 16mm holes at 50mm centres (4x holes deep)
  • 16mm securing hole 50mm apart on centres to work with all 16mm tooling and tables
  • Super strong Interlocking sub-frame every 4/5 holes spacing
  • 16mm holes on 50mm centres or 28D on 100mm Centres work with industry standard 16mm & 5/8" tools. Optional threaded holes and other holes sizes available.
  • Using our large range of welding table tooling, squares, stops, blocks and more, you can adapt the size and shape of your welding fixture table to suit your fabrication needs.
  • Option: Footmaster Castors 100S 2000kg – Height adjustable
  • Design, Manufactured in the UK
  • Blue powder-coated legs as standard
  • Table legs made of profile 100x100mm
  • Capacity: 850 kg/leg (adjustable footplate not FM Castors)
  • The highest quality of workmanship
  • Perfect flatness of the table (+/- 0,5 mm)
  • Holes of system ø16 in grid 50x50 or ø28 in the grid 100x100
  • Chamfered and fibre laser cut holes for easy tool assembly
  • Height adjustment of the table with standard legs approx. 880-930mm
  • Etched scale in the grid 50x50 or 100x100mm
  • Possibility of using stainless steel covers
  • Tables can be combined freely to extend a working surface
  • All tables are reinforced with structural ribs
