40mm Max Cuts
Cuts Steel
Aluminium
R-Tech I-Cut100 Plasma Cutter 415V (40mm Cutting Kit)
0% Finance Available - Select pay by finance in checkout - Instant decision
- Built with class leading Siemens IGBT's - Not inferior Mosfets
- HF pilot arc for easy starting even on painted surfaces and HF pilot re-start - ideal for cutting mesh etc.
- 35% Industrial duty cycle @ 100amps
- 32mm Genuine clean cut on mild steel, 21mm Genuine clean cut on alloy & stainless steel
- 40mm severance cut on mild steel
- 5 year collect and return UK warranty - What is this?in the unlikely event of machine failure, R-Tech will pay to collect, repair and return the Plasma Cutter to you quickly- No quibble warranty
- Digital display for amps - Ideal if you need your equipment calibrating for ISO requirements
- Industrial quality metal chassis
- Comes as a complete kit all you need is a supply of compressed air and a 415 V 32Amp supply
- Quick Fit Euro Torch with long life consumables
- Free Large Consumables Kit - 15 x Tips & 10 x Electrodes & 1 x Gas Distributor & Spacer - Keeping you cutting for longer!
Want to try before you buy? Book a demonstration at our Tewkesbury HQ - Available 5 days per week 9am-12pm and 2pm-4pm.
| Amperage Range | 20 - 100A (60% Duty cycle) | ||
| Input voltage/amps | 415v 32A | ||
| Clean cut mild steel | 32mm | ||
| Severance cut mild steel | 40mm | ||
| Clean cut aluminum | 24mm | ||
| Clean cut stainless steel | 24mm | ||
| Air consumption | 220Ltr/Min @ 75PSI | ||
| Net weight | 24KG | ||
| Dimensions | 515 x 220 x395 mm | ||
| Post flow air | Yes - Cools torch when cutting stopped | ||
| HF Pilot Arc Starting | Yes - Enables easy arc starting | ||
| HF Pilot Arc Re-start | Yes - Enables easy cutting of mesh | ||
| Cooling fan | Yes - Cooling fan with thermostatic protection | ||
- Generator Friendly - Generator must be minimum of 12KVA and fitted with AVR (auto voltage regulation)
- HF pilot arc enables easy starting of cut - even on painted surfaces
- Digital display for amps - Ideal if you need your equipment calibrating for ISO requirements.
- Industrial quality metal chassis
- Quick Fit Euro Torch with long life consumables
- Package Includes, R-Tech Plasma I-Cut 100P plasma cutter,6m plasma cutter torch, earth lead, mains cable, air pressure regulator & PCL fitting, owners manual, torch consumables kit - 5x tips/electrodes, 3x ceramic Cups
- 5 year collect and return UK warranty - What is this?in the unlikely event of machine failure, R-Tech will pay to collect, repair and return the Plasma Cutter to you quickly- No quibble warranty
The R-Tech I-CUT100 carries the following warranty:-
- I-CUT100 - 5 Year Warranty
- I-CUT100 Plasma Torch - 3 Month Warranty
- Earth Lead - 3 Month Warranty
R-Tech machines are designed to be robust, easy to use and highly reliable but in the unlikely event that your welder or plasma cutter requires attention, R-Tech promise to:-
- Arrange collection via next working day UK courier [48hr offshore]
- Quickly repair the machine at our Technical and R&D centre in Gloucester
- Deliver back via next working day UK courier [48hr offshore]
- All costs covered by R-Tech - Yes, Collection, repair and delivery!
No questions, no hassle, just honest and reliable service - A true no quibble warranty
Most of our competitors only offer return to base [RTB] warranties - you have to pay and arrange to get it back to them which can be a hassle. Many others offer warranties that have clauses and if you don't have it serviced yearly by them, at your cost, the warranty will be void.
Other benefits of owning an R-Tech machine include:-
- Free friendly and knowledgeable technical advice via phone and email
- Free machine setup help always available - We want you to get the best from your machine
- Ten year Duty-of-Care on all our machines, giving you piece of mind that spare parts will be available if needed
- Video's to show how to use and setup your R-Tech machine.
- 2 year extended warranties available at a minimal cost.
Don't just take our word for it - see our customer reviews page to see what real customers say about the R-Tech products and our service & support.
Excellent
R-Tech I-Cut100 Plasma Cutter 415V (40mm Cutting Kit)
calculated from 19 customer reviews
latest reviews
-
13 June 2024GREAT SERVICE AND VERY HELPFUL COMPANY
-
29 March 2024General fabrication work.
-
25 March 2024awesome machine
-
23 January 2024Works well but not fully tested yet
-
14 March 2023I use it about twice a week last Job was cutting pit some 30mm base plates. I have and frequently do recommend RTech products to folk. The fact I now own 4 Rtech machines speaks for itsself. 1st class kit.
-
02 July 2022Looks well built
-
09 November 2021Weill recommend
-
19 May 2021Heavy use in farm workshop cutting up to 25 mm plate Would recommend to any professional prefabricator Quality of product is faultless
-
08 February 2021It?s all just fantastic! Thank you
-
19 February 2020Very good cut with minimal demo time with the customer ! .
-
10 October 2019***
-
13 May 2019Excellent machine , really pleased with the service and quality
-
16 January 2019We cut all sorts of material in our workshop from 1.5 up to 30mm plate,mild steel, aluminium and stainless.This machine does everything we want it to. I would highly recommend it to anyone looking for a versatile plasma cutter It?s very well made and great people to deal with
-
27 September 2018Great product still early days, only reason you don?t get 5 stars is the user manual NEC updating to match the machine
-
02 February 2018Excellent product
-
17 October 2017I cut large amounts of 25-30mm steel for truck bodies, pipework, and structural steel. It cuts through this material a great deal faster than OxyAcetylene and is more cost effective at it at the same time. It is easily movable, easily set up and very smooth to use for the operator too.
-
22 March 2017All good and great advice for my requirements
-
09 November 2016Recomnd for metalworking companys
-
24 August 2015When I first saw it I thought that can't be as good as our old machine as it was much smaller, boy was I wrong as this machine packs a punch. Cut some 1 inch steel straight out the box and must say i'm very impressed. It was delivered next day as promised. I'll be back for a tig welder soon. Thanks Donald
-
What is included with the R-Tech Plasma Machine?
All of our machines include everything to get you welding as quickly as possible, at no additional cost. All you need to do is add your air supply to get going.
All of our Plasma Cutters include the following, in the box, at no additional cost.
- 4.5M Plasma Cutter Torch
- Earth Lead
- Mains Cable
- Air Pressure Regulator
- Owners Manual
- Torch Consumables, Including Tips, Electrodes and Swirl Rings
Additional items such as a Circle Cutting Kit and/or Trolley can be purchased as an optional extra, in the drop down menus.
-
Will this machine cut Aluminium?
Yes, all R-tech Plasma machines will cut aluminium. It is worth noting that the maximum cut will be reduced to around half when cutting aluminium.Â
-
Do I need a separate water/moisture trap to use an R-Tech Plasma Cutter.Â
All of our machines are fitted with air filters and should not require any additional filtertration to be required. All of our filters are easily accessible and fitted with a moisture trap, this can simply be emptied by pushing the button located at the bottom of the filter.Â
We do suggest additional filtration where the enviroment maybe quite humid and also in the winter when condensation can build up in the air lines.
-
What gas do I use to run a plasma cutter?
Plasma cutters run on compressed air. It is important to ensure your compressor is suitable for your machine. Details of the machines air consumption can be found in the tech specs tab.Â
-
How Long Will It Take To Get My ICUT100?
All orders for R-Tech welding equipment received by 3PM will normally be despatched the same day for next day delivery to the UK mainland, UK Isles may take 48hrs.
Once your order has been placed, will will email you an order confirmation, then a despatch confirmation with tracking number so you can track your order. We mainly use DHL who will often provide a 1 hour delivery time to you.
Simply order on-line or by phone on 01452 733933.
If you require any advice on which welding machine will best suit your requirements, please give us a all and one of our friendly sales/technical team will answer your questions
-
